規(guī)格
認證/合規(guī)Laser Certification: Class 3B laser deviceReported to the FDA
暗噪聲≤16.5 counts at 10 sec. integration
深度（公制）25 cm
檢測器Thermally stabilized CCD (2 stage TEC)
電氣要求Hertz: 50/60 Hz
光纖條件FC/PC (Both excitation and collection)
高度（公制）7.7 cm
包括Wireless mouse, HDMI cable, monitor
激光功率Laser Excitation Wavelength: 785 nm, Excitation power: 10 to 450 mW
工作溫度范圍15°C to 33°C
端口1RJ-45 Ethernet port 3 USB 3.0
分辨率Spectral Resolution: 6.5 cm-1 average across spectral range
安全特性1 keyed Laser interlock switch, Electronic laser trigger
軟件詳情MarqMetrix Raman suite Controller: Integrated PC (Windows 10 OS)
光譜范圍100 to 3250 cm-1
寬度（公制）25 cm
Unit SizeEach
